Acrel Energy Consumption Monitoring Solution for Base Station
General
It is necessary to measure and monitor electrical parameters and measure energy in AC side of tower base station such as state grid, diesel, air conditioner, lighting, power supply and so on. In DC side, it is necessary to monitor electrical parameters and measure energy such as base station communication device, battery and other devices working under -48V power supply. The data can be real-time uploaded by RS485.
Application Scenario
• Mobile telecom
• Telecommunication carrier
• Communication base station
Structure
Main Functions
• Measurement: Multi circuits voltage, current, power, energy and other electrical parameters
• Communication: RS485 Modbus-RTU,NB or 4G
• Certificate: With CE and IEC
• Accuracy: 0.5s or 1
On-site Pictures
Typical Cases
Acrel Wireless Temperature Monitoring System Applied in Beijing Daxing International Airport - view more
Acrel Wireless Temperature Monitoring System Applied in Project in Italy - view more
Acrel Wireless Temperature Monitoring System Applied in Project of Lotte Mart in Hanoi Vietnam - view more
Product Selection
| Picture | Model | Main Function |
 |
AMC96L-E4/KC Multifunction Meter | True RMS Measurements;
THD with 2-31st Harmonics;
Max/Min Log with Timestamp;
Internal Optional 4DI&2DO or 2DI&2DO&2AO;
Standard one Energy Pulse Output.
|
 |
AMC96N-4E3 Multi Circuits AC Energy Meter | Installation: panel mounted;
4 circuits 3 phase or 12 circuits single phase AC input, external CTs,50/60HZ;
Measurement: voltage, current, energy and other parameters;
Communication: RS485 Modbus-RTU.
|
 |
DTSD1352-4S | Measure Up to 4 circuit 3 phase;
Measure all electric parameters;
Split core open loop CTs;
External function module, such as MK(switching inputs and outputs), MTL(temperature measurement and leakage current measurement), AWT100(wireless communication).
|
 |
AMC16-DETT Base Station DC Energy Meter | DC rated voltage: 1 channel: -48VDC;
Accuracy:1%In≤I≤10%In error±2.5%; I>10%In error±2%;
RS485(MODBUS-RTU);
LED display;
DIN 35mm.
|
 |
ADW350 Wireless Energy Meter | DIN 35mm;
3 circuits DC input or 1 circuit 3 phase AC input;
3 circuits DC input or 1 circuit 3 phase AC input;
Communication: NB or 4G.
|
 |
AHKC-E Hall sensor | Measurement;
AC, DC, pulse and other complex current.
|
